执行标准：欧盟EN12209:2016，20万次开启标准
EN1634-1:2012，4小时防火标准
中国GB12955-2008，90分钟3C防火标准
舌头配置：SUS304精铸斜舌
面板配置：高级耐指纹盖板, SUS304面板
拨轮配置：高精度钢制，一体式
表面处理：不锈钢拉丝，沙金PVD
适用门型：木质门、钢质门等
适用区域：管井门，机房门等
Compliance:EN12209:2016, 200,000 life cycle
EN1634-1:2012, 4 hours fire rated
Dead bolt and latch bolt are made by casting stainless steel 304
Forend is anti-figerprint stainless steel 304
Finish: SS, satin PVD, polished PVD, polished
Suitable for woodend and steel door, flat door, rebated door
Application: fire door, smoke door
把手配置：圆环拉手和分体钥匙盖
锁体配置：钢木螺丝
锁芯为单开或者双开，长度依据门厚确定
适用标准门厚45-50MM,选配门厚51-70MM
Handle: Two activity handle for both side, 4 sets of through bolt.
Lock: screws and 8* 8*100mm spindle
Cylinder: key/key or half cylinder
Suitable for door thickness 45~50mm.51~ 70mm thickness is optional.
管井门：门内无锁定，门外钥匙开启拉环开门
机房门：门内门外均钥匙开门
钥匙可纳入总钥匙管理系统，实现统一管理
Tube wells door: half cylinder, lock or open ouside by key
Equiment door: inside and outside open by key
Master key is available
