执行标准:欧盟BS EN12209:2016,20万次开启标准

                         BS EN1634-1:2012,4小时防火标准

              中国GB12955-2024 3小时及CCCF自性认证

舌头配置:SUS304精铸斜舌、方舌

表面处理:不锈钢拉丝、沙金PVD、亮光PVD、镜光

适用门型:木质门、钢质门、平口门、企口门等

Compliance:BS EN12209:2016,200,000 times life cycle
                  BS EN1634-1:2012,4 hours fire rated
                  GB12955-2024 3 hours and CCCF voluntary certification
Dead bolt and latch bolt are made by casting stainless steel 304
Forend is anti-figerprint stainless steel 304
Follower is casting stainless steel 304
Finish:SS,satin PVD, polished PVD, polished
Suitable for wooden and steel door , flat door, rebated door
Application:entrance door, fire door, smoke door,etc

锁体配置:钢木螺丝及标准100MM长8*8方杆

锁芯为单开或者双开,长度依据实际门厚确定

适用标准门厚45-50MM，选配门厚51-70MM

Handle: Two activity handle for both side, 4 sets of through bolt.

Lock: screws and 8*8*100mm spindle

Cylinder: key/key or half cylinder

Suitable for door thickness 45~ 50mm.51~70mm thickness is optional.

逃生门:门内压把手开门，门外钥匙开门

钥匙可纳入总钥匙管理系统，实现统一管理

Exit door: rotate the handle to open the door from inside, by key from outside

Master key is available
