产品特点:符合美国ANSI156.13-2022-级标准

              符合UL10C防火标准

              门内旋钮可直观反馈门锁是否上锁

锁体:高强度钢质锁体，表面镀锌，耐腐蚀方舌，一体式精铸

方舌：25mm行程

保险舌:精铸不锈钢锁扣板:不锈钢，不分左右，采用ANSI标准尺寸，1-1/4"-718"(32*124mm)

适用门厚:标准1-3/4"(45mm),可选1-3/8(35mm),2-1/2(64mm)

门边距:2-3/4"(70mm)

Specification:Compliance with ANSI A 156.13-2022,Grade 1.

                   Compliance with UL fire rated.
                   Locking thumbturn on the inside of door visually shown when the dooris lockedand unlocked.

Lockcase:Heavy gauge steel,with zinc dichromate finish for corrosion resistance.

Deadbolt:One-piece stainless steel,25mm throw.

Latchbolt:Stainless steel,2 piece mechanical with anti-frction insert,19mm throw.

Auxiliary Latchbolt:Stainless steel.

Strike:Stainless steel,ANSl straight lip standard,4-7/8"(124mm)*1-1/4"(32mm).

Door Thickness:1-3/4"(45mm)standard.Optional 1-3/8"(35mm),2-1/2"(64mm).

Backset:2-3/4"(70mm)
