执行标准:美国ANSIA156.13-2005一级锁标准,通过100万次转动测试
UL3小时防火,获行BHMA列名证书
中国GB12955-2008防火标准,90分钟防火标准
锁体:高强度钢质锁体
固定式方舌:精铸不锈钢,1"(25mm>行程,备防锯淬火钢棍
斜舌:精铸不锈钢三段式,3/4" (19mm>长,带抗摩擦前导舌
辅助保险舌:精铸不锈钢
锁扣板:不锈钢,不分左右手,采用ANSI标准尺寸1-1/4"x4-7/8"(32mmx124mm)
适用门厚1-3/8" (35mm> 2-1/2-<64mm),标准门厚1-3/4"(45mm )
安装门边距2-3/4(70mm)
●Certification and Compliance: ANSI A156.13-2005, Grade 1
●UL Fire Rated 3 Hours, BHMA Certification
●GB12955 3008 Fire rated 90 mins
●Lockcase: Heavy gauge steel, with zinc dichromate finish for corrosion resistance.
●Deadbolt One piece stainless steel, 25mm throw.
●Latchbolt:Stainless stee, 2 piece mechanical with ani-icion insert. 19mm throw.
●Aiullary Lathbolt: stainless steel
●Strikestainless steel, ANSI straight lip standard, 4-7/8* (124mm) x 1-1/4" (32mm).
●Door Thickness: 1-3/4" (45mm) standard. Optional 1-3/8"(35mm), 2-12(64mm)
