门外①:配置电控把手锁，需读卡授权释放把手（断电开）开门，压把手开门门外

     门外②:配置机械把手锁,需钥匙解锁把手，压把手开门

2、门锁主体采用12v供电,断电后主体实现纯机械工作原理

3、以上功能可适用单门门锁和双门门锁;

5、认证:UL305 50万次

             UL10C 1.5小时防火

6、可选AN SI/BHMAA 156.29- 1级50万次认证

1. Door①: When working,press the handle voice alarm,delay 1-15 seconds after the alarm islifted, push the handle to open the door
   Door②: Adopt the main key reset function, remove the alarm,push the door
Outside the door①: Electronic control handle lock,need to read the card to authorize the release handle (power offl to open the door,pressthe handle to open the door
Outside the door②: Equipped with mechanical lock handle, need key to unlock handle . press handle to open the door
2. The main body of the door lock adopts 12V power supply. After power is cut off, the mainbody realizes pure mechanical working principle
3. The above functions can be applied to single door lock and double door lock
4. Optional online digital display:BDE
5. Certification:UL305 500,000 times UL10C 1.5 hours fire protection
6. Certificate ANSI/BHMA A156.29, grade 1 cycle test 500,000 times
