电源:1路12V直流供电电源.1路12V直流备用电源
声源:读写各种语言的语音+警笛 输出3组用于警灯控制和输出到总控制室等,1组输出
消防联动反应时间:小于1秒
强行开门报警反应时间:小于1秒
强行开启延时开启时间:5-30秒
输入:1组烟雾探测器
1组手动报警器
1组门禁系统
通信:2组RS485通信系统
Power supply: 1 way 12V DC power supply.
1 way 12V DC backup power supply.
Sound source: read and write the voice of various
languages + siren Output 3 groups for police
light control and output to the main control room,
etc., 1 group output
Fire linkage response time: less than 1 second
Alarm response time for forced door opening: less than 1 second
Forced opening delay opening time: 5-30 seconds
Input: 1 group smoke detector
1 group of manual alarm
1 group of access control system
Communication: 2 groups of RS485 communication system
1.系统采用模块化开发，每个逃生门锁配备一块电路板.完成各种的信号采集和输出
2.系统可连接多达256个逃生门锁
3.独立电脑软件控制
4.可实现门禁联网，消防联动
5.可为消防系统，监控系统开发接口，接入到各种不同的消防系统和监控系统
6.配主体语音播报功能
1. The system adopts modular development, each escape door lock is equipped with a circuit board. Complete the
2. System can be connected to up to 256 escape door locks
3. Independent computer software control
4. Can realize access control networking. Fire linkage
5. for the fire system, monitoring system development interface,access to a variety of different fire systems and monitoring systems
6. with the main voice broadcast function
1、消防联动功能:可通过自主开发的系统软件实现联动。在控制室即时关注门的状态
2、烟感报警功能:当烟感启动时，驱动逃生门锁语音及警笛报警，引导逃生并将信号反馈到控制室
3、系统反馈功能:控制室专业电脑界面显示锁的控制状态如下10种:
1)正常关闭状态
2)长开状态
3)长开井超过延时时间状态
4)强推井且关闭状态
5)强推并且打开状态
6)门禁并且打开状态
7)紧急并且关闭状态
8)紧急并且打开状态(未授权)
9)紧急并且打开状态(授权)
10)远程锁闭并且关闭状
1.System is 485 communication protocol
2.Can connect to smoke detector, munual alarm, outside trim, vediomonitortomonitor the status
3.Light and speaker will be promoted under any un-authorise action
4.All action are monitored and controled by the center computer
5.Maxinum to 256 panic exit device6.Special sotfware to insert to the other system, such as buildingautomaticfireextinguishing system
