Compliance:
1)ANSI/BHMAA156.4, C07111
2) UL10C, 3 hours fire rate
3) China GB12955-2008, 1.50 hours fire rated
Specification:
1) Stainless steel 304, super anti-corrosive, durable,
attractive and easy to clean.
2). Additional thrust bearing for greater load capacity, dust proof.
3) For wood door and metal door, weight to 1,650 Ibs(750kg)
4) Door edges must be beveled in 1/8* in 2"
5) Mininum door thickness 50mm
6) Vertical adjust 4.5mm
7) Handed
8) Finish: SSS, PSS, PVD
Marks: .
Use for door heights over 7'0" and one every 2'6"or .
Use for door weight over the pivot set limit.
One additional for every additional 100 pounds
