执行标准:欧盟BS EN12209:2016,20万次开启标准
BS EN1634-1:2012,4小时防火标准
中国GB12955-2024 2小时及CCCF自愿性认证
舌头配置:SUS304精铸斜舌
面板配置:高级耐指纹盖板,SUS304面板
拨轮配置:高精度钢制,一体式
表面处理:不锈钢拉丝、沙金PVD等
适用门型:木质门、钢质门
适用区域:管井门、机房门
Compliance:BS EN12209:2016,200,000 times life cycle
BS EN1634-1:2012,4 hours fire rated
GB12955-2024 2 hours and CCCF voluntary certification
Latch bolt are made by casting stainless steel 304
Forend is anti-figerprint stainless steel 304
Follower is casting stainless steel 304
Finish:SSS,Satin PVD,Polished PVD, Polished ,etc
Suitable for woodend and molded door, etc
Application: Pipe well door, machine room door
把手配置：圆环拉手和分体钥匙盖
锁体配置：钢木螺丝
锁芯为单开或者双开，长度依据实际门厚确定
适用标准门厚45-50MM,选配门厚51-70MM
Handle: Two activity handle for both side, 4 sets of through bolt .
Lock: screws and 8* 8* 100mm spindle
Cylinder: key/key or half cylinder
Suitable for door thickness 45~50mm.51~70mm thickness is optional.
管井门：门内无锁定，门外钥匙开启拉环开门
机房门：门内门外均钥匙开门
钥匙可纳入总钥匙管理系统，实现统一管理
Tube wells door: half cylinder, lock or open ouside by key
Equiment door: inside and outside open by key
Master key is available
