EN1634-1:2012，4小时防火标准

              EN179:2008.逃生标准

              中国GB12955-2008.90分钟3C防火标准

面板配置:高级耐指纹盖板、SUS304面板

拨轮配置:高精度钢制、分体式

表面处理：不锈钢拉丝，沙金PVD等

适用门型：木质门、钢质门等

适用区域：教室门

Compliance: EN12209:2016+ EN179, 200,000 life cycle

                  EN1634-1:2012, 4 hours fire rated

Latch bolt are made by casting stainless steel 304, 4mm

Forend is anti-figerprint stainless steel 304

Follower is casting stainless steel 304

Finish: SS, Satin PVD, Polished PVD, Polished

Suitable for woodend and steel door, flat door, rebated door

Application: classdoor , office door, partition door

把手配置：内外均为活动把手，款式可选；

锁体配置：钢木门螺丝及分体式100MM长8*8方杆；

锁芯为单开或者双开，长度依据实际门厚确定

适用标准门厚45-50MM，选配门厚51-70MM

Handle: Two activity handle for both side, 4 sets of through bolt .

Lock: screws and 8*8*100mm spindle

Cylinder: key/key or half cylinder

Suitable for door thickness 45~ 50mm.51~70mm thickness is optional.

教室门：上锁时，门内压把手门开，门外钥匙开门 开锁时，门内门外均压把手开门

钥匙可纳入总钥匙管理系统，实现统一管理

Latchbolt retracted by lever from either side unless outside is locked by key.Unlocked from outside by key. Inside lever always free forimmediate exit.

Master key is available
