信号输出:干接点输出，最大承受功率3A

锁体尺寸:长258×宽65.8×厚38.8(mm)

吸板尺寸:长185×宽60×厚13.2(mm)

最大拉力:500kg(1200Lbs)直线拉力

输入电压:DC12V(可调DC24V)

工作电流:12V/500mA(+10%)；24V/250mA(+10%

适用门型:木门、金属门、有框玻璃门

锁体材质:铝合金

防水等级:IP65

Signal Output: Dry Contact,Max Rating of Contact Current 3A

Lock Size:258L×65.8W×38.8H(mm)

Armature Plate: 185L×60W×13.2H(mm)

Holding Force: 500kg(1200Lbs)

Input Voltage: DC12V(Adjustable DC24V)

Current Draw:12V1500mA(+10%);24V1250mA(+10%)

Suitable For: Wooden/Metal/Framed Glass door

Cover Finish: Aluminium Alloy

IP Rate:IP65
Operating Temp:-20°C~+55°C(-4-131'F)
