信号输出:锁状态信号NO/NC/COM接点

锁体尺寸:长250×宽47×高27(mm)
吸板尺寸:长190×宽45×高13.2(mm)
最大拉力:350kg(750Lbs)直线拉力
输入电压:DC12V(可调DC24V)

工作电流:12V/500mA(±10%)；24V/250mA(±10%)

适用门型:木门、金属门、有框玻璃门
锁体材质:304不锈钢

防水等级:IP65

Signal Output: Lock signal(NO/NC/COM)

Lock Size:250L×47W×27H(mm)

Armature Plate: 190L×45W×13.2H(mm)

Holding Force: 350kg(750Lbs)

Input Voltage: DC12V (Adjustable DC24V)

Current Draw: 12V/500mA(±10%);24V/250mA(±10%)

Suitable For: Wooden/Metal/Framed Glass door

Cover Finish: Stainless Steel

IP Rate:lP65

Operating Temp:-20'C~+55'C(-4-131'F)
