信号输出:锁状态信号NO/NC/COM接点
锁体尺寸:长196x宽35x厚20.5(mm)
吸板尺寸:长130x宽32x高10(mm)最大拉力:180kg(350Lbs)
直线拉力输入电压:DC12V(可调DC24V)
工作电流:12V/400mA(+10%)；24V/200mA(+10%)
适用门型:木门、金属门、有框玻璃门
锁体材质:304不锈钢
防水等级:IP65
工作温度:-20℃~+55℃(-4-131°F)
Signal Output: Lock signal(NO/NC/COM)
Lock Size:196L×35W×20.5H(mm)
Armature Plate Dimension: 130L×32×10H(mm)
Holding Force: 180kg(350Lbs)
Input Voltage: DC12V(Adjustable DC24V)
Current:12V/400mA(+10%);24V/200mA(+10%)
Suitable:Wooden/Metal/Framed Glass door
Cover Finish: Stainless Steel
lP Rate:lP65
Operating Temp:-20C~+55℃(-4-131°F)
