澳标插芯锁体说明
执行标准:澳标AS 4145.2-1993
澳标AS 1905.1-2005防火4小时.
中国GB12955- 2008防火标准，90分钟防火
斜舌:不锈钢304
面板配置:高级SUS304不锈钢锁壳及面板
方向开启:斜舌可换向，不分左右方向
适用门型:木质门、钢质门、平口门、企口门等
表面处理:不锈钢拉丝，沙金PVD，亮光PVD,抛光
●Compliance:AS 4145.2-1993
AS 1905. 1-2005, fire rated 4H
GB12955- 2008，fire rated 3H
●Latchbolt: stainless steel 304
Forend: anti-figerprint stainless steel 304
●Non handed
Suitable for wooden and steel door , flat door, rebated door
Finish: ssS, PSS, PVD
澳标功能锁体
澳标插芯锁，选材优质，强度高，寿命长，高安保。
广泛应用工业和商业场所，培训机构，俱乐部，学校，医院，宾馆等。
高安保:达到澳标AS-4145.2-1993, S3等级.
长寿命:达到澳标AS-4145.2-1993, D3等级
防火:达到澳标AS 1905. 1-2005，4小时防火等级
锁芯:5针椭圆形锁芯，不同的功能需要配置不同拨片
Cylinder mortice locks are made from quality
Locks are made from quality materials to meet high durabilityand strength requirements.
A wide range of security cylindermortice locks and latches suita ble for heavy duty use
inindustrial and commercial buildings,institutions, clubs, schoolshospitals,hotels and
similar buildings.
Security
Locks conform with Level S2(Physical Security )Australian LockStandard(AS-4145.2-2008)LevelS7
Fire Rating
Locks compliance with four hours fire rated (depending on typeof doorset) on fire door assemblies in accordance with AustralianStandard AS 1905.1-1905: Fire Resistant Doorsets.
Cylinder
Bump resistant five pin tumbler mechanism. Standard oval shapedbrass cylinders and brass barrels. Functions require the use ofdifferent cams and adaptors.
