Compliance: ANSI 156.4, Grade 1.
GB 12955-2008, 90 mins fire rated
UL, 3 hours fire rated
Material; stainless steel (SUS 304)
Finish: SSS, PVD, PS
Suitable for wooden doors and steel doors
Precision bearings for smooth operation with dust proof.
Description;
No handed.
Min door thickness: 45mm
Be adjustable for 4.5mm in vertical direction.
Load capacity: 700Ibs (320KG)
Notes:
When the standard load capacity is more than 45 KG, a
intermediate pivot should be configured!
When the door is taller than 2200 mm , a intermediate pivot
should be configured !
