AD100/AD101中心/偏心天地轴
产品认证
符合ANSI156.4一级性能标准符合UL3小时防火标准
符合国家GB12955-2008防火90分钟标准
产品特性
产品部件全部使用抗腐蚀优质304不锈钢材质精铸不锈钢锻造适用防火及非防火门
精密轴承动作顺滑,并做防尘处理适用超重木门,钢质门等
饰面处理可选:SSS,PVD,PS等
产品描述
产品安装不分左右手向适用最小门厚45毫米
最大适用门重220磅(100KG)
Compliance: ANSI 156.4. Grade 1.
GB 12955-2008, 90 mins fire rated
UL, 3 hours fire rated
Material: stainless steel (SUS 304)
Finish: SSS, PVD, PS
Suitable for wooden doors and steel doors
Precision bearings for smooth operation with dust proof,
Description:
No handed.
Min door thickness: 45mm
Load capacity: 220 Ibs (100KG)
