停门功能块为可选配件
不分左右方向开启
材质说明:铝铸一体式缸体表面处理:烤漆银/烤漆金门最大开启角度120°
闭门速度120-15°可调
闭锁速度15-0°可调
最小安装门厚:金属门38MM，木质门42MM
Compliance:EN1154、EN1634-2H
XF93-2004 G1, fire rated
F unction:
Adjustable closing & latching speed
Suit for wooden and steel door
Optional built in HOLD-open
Non-handed
Material:
Cast aluminum alloy body
Finish: silver, optional golden
Feature:
Spring power EN2/3,door weight 40-60KG
Max door width 950mm
Max opening angle is 120°degree
Closing speed adjustable in the range 120-15°degree
Latching speed adjustable in the range 15-0°degree
Min door thickness: steel door 38mm, wooden door 42mm
