执行标准:机械性能通过欧洲EN12209-2016,20万次开启标准
逃生性能通过欧洲EN179:2008
信号输出:常开C/NO,常闭C/NC
开锁状态:断电开锁
工作电压:12V
工作电流:运行0.3A,待机0.1A
额定功率:12.5W
耐压电流:1A
寿命:30万次
适用门厚:标准门厚45-50mm，选配门厚51-70mm
表面处理:SS, PVD,PS
方向开启:不分左右开启
适用门型:木质门或者金属门
适用区域:高保安的公共场所
可纳入美标/欧标混合总钥匙系统
Compliance wit: EN12209:2016+ EN179, 200,000 life cycle
EN1634-1:2012, 4 hours fire rated
Signature output: C/NO, C/NC
Locked status: motor lock/unlock
Input volt: 12V
Current: Max 0.3A, idle 0.1A
Power ratings: 12.5w
Voltage current: 1A
Cycles: 300,000
Suitable door thickness: 45-50mm
Optional door thickness: 51-70mm
Finish: SS, PVD, PS
Non handed
Fit for metal and wooden door
Application to the public building with high security
Master key with ANSI/BHMA cylinder is available
